Slash Assembly Time
Process 1300×2500mm panels in 90 seconds (vs. 8+ mins manual)
No forklift needed – integrated lifting cylinders
Why choose this machine?
Slash Assembly Time
Process 1300×2500mm panels in 90 seconds (vs. 8+ mins manual)
No forklift needed – integrated lifting cylinders
Eliminate Glue Waste
Uniform pressure ensures 99.9% adhesive coverage
Reject rate drops from 5% → 0.3% on curved laminates
Future-Proof Integration
OPC-UA protocol connects to MES/ERP systems
Remote diagnostics via HMI touchscree
“The A/B-side control lets us press acoustic panels with different face/back materials in one cycle.”
—Architectural Studio
Industries Transformed
Boatbuilding: Hull panels
Construction: Cross-laminated timber (CLT)
Aerospace: Cabin interiors
Furniture: Bentwood luxury pieces
Certifications & Compliance
CE
|
Model |
MH2500 |
MH4600 |
MH5200 |
MH6200 |
|
Max. Working Length(mm) |
2500 |
4600 |
5200 |
6200 |
|
Max. Working Width(mm) |
1300 |
1300 |
1300 |
1300 |
|
Max. Working Thickness(mm) |
150 |
150 |
150 |
150 |
|
Top Cylinder Diameter(mm) |
80 |
80 |
80 |
80 |
|
Top Cylinder Amount on Each Side |
6pcs |
12pcs |
14pcs |
16pcs |
|
Side Cylinder Diameter(mm) |
40 |
40 |
40 |
40 |
|
Side Cylinder Amount on Each Side |
6pcs |
12pcs |
14pcs |
16pcs |
|
Side Lifting Cylinder Diameter(mm) |
63 |
63 |
63 |
63 |
|
Side Lifting Cylinder Amount |
2pcs |
4pcs |
4pcs |
4pcs |
|
Motor Power(kw) |
5.5 |
5.5 |
5.5 |
5.5 |
|
Weight(kg) |
3800 |
6800 |
7200 |
9000 |
|
Overall Dimension(mm) |
3100*2300*2320 |
5400*2300*2320 |
6000*2300*2320 |
7000*2300*2320 |
